Planet PL-ELA-100 Ethernet Lightning Arrest Box

Planet PL-ELA-100 Ethernet Lightning Arrest Box PLANET has introduced a specialized Ethernet Lightning Arrest Box, Planet PL-ELA-100. This device is a network accessory with surge protection capabilities. It is designed to safeguard Ethernet devices from potential damage caused by surge voltages resulting from lightning strikes, The Planet PL-ELA-100 Ethernet Lightning Arrest Box features two passive 10/100/1000Base-T interfaces, allowing seamless connection of two Ethernet devices, along with a designated ground position for proper earthing. With the ELA-100 Ethernet Lightning Arrest Box, you can rest assured that your Ethernet devices are protected from surge voltages caused by lightning strikes, making it an ideal solution for ensuring the safety and longevity of your network equipment.   Specifications Details Ethernet interface 2 passive 10/100/1000 Ethernet ports Ground 1 ground position DC spark-over voltage 230V, ±20% Nominal impulse discharge current (wave 8 / 20μs) 20KA Arc Voltage at 1A ~35V Glow to arc transition current ~1A Glow voltage ~200V Dimensions (W x D x H) 65 x 42 x 20mm Weight 80g Operating environment 0~50 degrees C, 5%~90%RH Storage environment -20~70 degrees C, 5%~90%RH
