The Rocket5ac Prism (RP-5AC-Gen2) is designed to deliver maximum spectral efficiency and throughput. Features 5 GHz Frequency Band With plenty of available spectrum, this unlicensed band works well for long‑distance links. The Rocket5ac Prism features full‑band 5 GHz coverage and maximizes output power for the US market, meeting strict OOBE requirements. airView Use the real‑time spectrum analyzer so you can identify noise signatures and design your wireless links to minimize noise interference. High Performance To take full advantage of its design and capabilities, deploy the Rocket5ac Prism for PtP or PtMP links in high RF noise environments. airPrism Sector Antenna You can mount three Rocket5ac Prism radios on the airPrism 5 GHz 3×30° HD Sector Antenna, model AP‑5AC‑90‑HD, for PtMP links. Each Rocket radio corresponds with a specific 30° beamwidth and independently transmits and receives. EMI-Shielded Metal Housing Helps protect the Rocket5ac Prism against electromagnetic interference. Gigabit Ethernet Delivers high throughput over its wired connection. Passive Power over Ethernet (PoE) 24V Passive PoE functionality is included. Both power and data are carried over a single Ethernet cable to the Rocket ac. Use the included PoE Adapter or an optional PoE switch. Plug and Play Integration Every airMAX antenna has a built‑in Rocket mount, so no tools are needed to install the Rocket5ac Prism. (airMAX ac antennas are recommended for optimal performance.) Antenna Characteristics Dimensions* 88 x 40 x 230 mm (3.47 x 1.58 x 9.06″) Weight 400 g (14.11 oz) Networking Interface (1) 10/100/1000 Ethernet Port LEDs (4) Signal Strength, GPS*, LAN, Power Channel Sizes PtP Mode (10/20/30/40/50/60/80 MHz) PtMP Mode (10/20/30/40 MHz) Cross-Polarization Isolation 30 dB Min RF Connectors (2) RP-SMA (Waterproof), (1) GPS* (Waterproof) Memory 128 MB DDR2 SDRAM Power Supply 24V, 1A Gigabit PoE Adapter (Included) Power Methods Passive PoE (Pairs 4, 5 ; 7, 8 Return) Modes Access point, Station
