The NBE-5AC-Gen2 NanoBeam ac High-Performance airMAX Bridge from Ubiquiti Networks directs RF energy in a tight beamwidth. It maximizes and improves noise immunity by its uniform bandwidth and also blocks or spatially filters out noise. This feature helps in areas crowded with other RF signals of the same or similar frequency. The Nanobeam ac combines the radio and antenna in an efficient and compact unit that gets maximum gain out of the smallest footprint. It features an innovative mechanical design and high speed processor for optimal performance at low cost. All-in-One Design The NanoBeam ac provides both the radio and antenna in the smallest possible footprint. Quick Assembly No fasteners are required for pole-mounting, and a single wall fastener (not included) is required for wall-mounting. Convenient Alignment The NanoBeam ac pivots on its ball joint for easy aiming. Efficient Footprint The radio and antenna are combined into a single body that takes up minimal space. Versatile Mounting The NanoBeam ac can be mounted in almost any position needed for line of sight. Aesthetics The NanoBeam ac is small enough to blend discreetly into the background at a customer’s location. General Specifications Processor Atheros MIPS 74Kc, 720 MHz Memory 128 MB DDR2, 8 MB flash Networking Interface 1 x 10/100/1000 Ethernet port Power Power Supply 24 V, 0.5 A Gigabit PoE Power Method Passive PoE (pairs 4, 5 and 7, 8 return) Power Consumption 8 W maximum TX Power Specifications Modulation: airMAX ac Data Rate: 1 x BPSK (½) Average TX: 26 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 2 x QPSK (½) Average TX: 26 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 2 x QPSK (¾) Average TX: 26 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 4 x 16QAM (½) Average TX: 26 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 4 x 16QAM (¾) Average TX: 26 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 6 x 64QAM (2/3) Average TX: 25 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 6 x 64QAM (¾) Average TX: 25 dBm Tolerance: ± 2 dB Modulation: airMAX ac Data Rate: 6 x 64QAM (5/6) Average TX: 24 dBm Tolerance: ± 2 dB Modulation: airMAX ac Data Rate: 8 x 256QAM (¾) Average TX: 22 dBm Tolerance: ± 2 dB Modulation: airMAX ac Data Rate: 8 x 256QAM (5/6) Average TX: 22 dBm Tolerance: ± 2 dB RX Power Specifications Modulation: airMAX ac Data Rate: 1 x BPSK (½) Sensitivity: -96 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 2 x QPSK (½) Sensitivity: -95 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 2 x QPSK (¾) Sensitivity: -92 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 4 x 16QAM (½) Sensitivity: -90 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 4 x 16QAM (¾) Sensitivity: -86 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 6 x 64QAM (2/3) Sensitivity: -83 dBm Tolerance: ± 2 dBModulation: airMAX ac Data Rate: 6 x 64QAM (¾) Sensitivity: -77 dBm Tolerance: ± 2 dB Modulation: airMAX ac Data Rate: 6 x 64QAM (5/6) Sensitivity: -74 dBm Tolerance: ± 2 dB Modulation: airMAX ac Data Rate: 8 x 256QAM (¾) Sensitivity: -69 dBm Tolerance: ± 2 dB Modulation: airMAX ac Data Rate: 8 x 256QAM (5/6) Sensitivity: -65 dBm Tolerance: ± 2 dB Antenna Gain 19 dBi Polarization Dual linear Operating Frequency 5150 to 5875 MHz 5725 to 5850 MHz Wind Loading 45.4 N @ 200 km/h (10.2 lbf @ 125 mph) Wind Survivability 200 km/hour (125 mph) LED Indicator Specifications LEDs 1 x Power 1 x LAN 4 x WLAN Signal Strength LEDs Software-adjustable to correspond to custom RSSI levels Channel Size Support PtP Mode 10/20/30/40/50/60/80 MHz PtMP Mode 10/20/30/40 MHz Environmental Operating Temperature -40 to 158°F (-40 to 70°C) Operating Humidity 5 to 95% (non-condensing) Tests Salt Fog Test IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 Vibration Test IEC 68-2-6 Temperature Shock Test IEC 68-2-14 UV Test IEC 68-2-5 at 104°F (40°C) Equivalent: ETS 300 019-1-4 Wind-Driven Rain Test ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5
