Ubiquiti R5AC Lite Rocket 5 ac Lite airMAX, Point to Point Wireless Bridge/Base Station

Ubiquiti R5AC Lite Rocket 5 ac Lite The Ubiquiti Rocket 5 ac Lite is an ac radio that is built with high performance and ease of installation in mind. The Ubiquiti R5AC-LITE offers the freedom to deploy anywhere in the world, and it allows for a high degree of flexibility in configuring channel bandwidths (subject to local country regulations). Ubiquiti Rocket 5 ac Lite Key Features ○ Frequency – Full-Band 5 GHz ○ Throughput – 450 Mbps ○ Ports – (1) 10/100/1000 Ethernet ○ Plug and Play Integration with RocketDish Antennas The Ubiquiti Rocket 5 ac Lite radio can be paired with a RocketDish antenna to create the endpoint of a high-performance, Point-to-Point (PtP) backhaul. Ubiquiti Rocket 5 AC Lite – Technical Specifications General Dimensions 162 x 84 x 37 mm (6.38 x 3.31 x 1.46″) Weight 250 g (8.81 oz) Enclosure Characteristics Outdoor UV Stabilised Plastic Processor Atheros MIPS 74Kc, 720 MHz Memory 128 MB DDR2 SDRAM, 16 MB NOR FLASH Networking Interface (1) 10/100/1000 Mbps RF Connections (2) RP-SMA (Waterproof) LEDs Power, Ethernet, (4) Signal Strength Max. Power Consumption 8.5W Power Supply 24V, 0.5A Gigabit PoE Adapter Power Method Passive PoE (Pairs 4, 5 ; 7, 8 Return) ESD/EMP Protection ± 24KV Air / Contact Operating Temperature -40 to 80° C (-40 to 176° F) Operating Humidity 5 to 95% Noncondensing Shock and Vibration ETSI300-019-1.4 R5AC Lite Software Information Modes Access Point, Station Services Web Server, SNMP, SSH Server, Telnet , Ping Watchdog, DHCP, NAT, Bridging, Routing Utilities Antenna Alignment Tool, Discovery Utility, Site Survey, Ping, Traceroute, Speed Test Distance Adjustment Dynamic Ack and Ackless Mode Power Adjustment Software Adjustable UI or CLI Security WPA2 AES Only QoS Supports Packet Level Classification WMM and User Customer Level: High/Medium/Low Statistical Reporting Up Time, Packet Errors, Data Rates, Wireless Distance, Ethernet Link Rate Channel Sizes PtP Mode 10/20/30/40/50/60/80 MHz PtMP Mode 10/20/30/40 MHz Other Remote Reset Support, Software Enabled/Disabled, VLAN Support, 256QAM, Ubiquiti Specific Features 30/50/60 MHz Channels, airMAX ac Mode, Traffic Shaping with Burst Support, Discovery Protocol, Frequency Band Offset, Ackless Mode R5AC Lite Compliance Wireless Approvals FCC, IC, CE RoHS Compliance Yes R5AC-PTP Operating Frequency Operating Frequency Worldwide: 5150 – 5875 MHz USA: 5725 – 5850 MHz Output Power 27 dBm
