Manufacturer: Ubiquiti Model: AMO-2G13 The Ubiquiti Omni AirMax MiMo Antenna 2.4GHz 13dBi is a Carrier Class 2×2 Dual Polarity MIMO omnidirectional antenna that was designed to seamlessly integrate with Ubiquiti Rocket M radios (Ubiquiti Rocket M sold separately). Ubiquiti Rocket M combines the “brains” in one robust unit; just pair Ubiquiti Rocket M with an Ubiquiti AirMax Omni to create powerful 360° omnidirectional base station. This seamless integration gives network architects unparalleled flexibility and convenience. Ubiquiti AMO-2G13 Key Features: Frequency – 2.4 GHz 13 dBi gain Wind Survivability up to 125 mph Plug-in and play integration Here is an example of how AirMax Omni can be deployed: 1: Internet Backbone 2: ISP Network 3: Ubiquiti RocketDish with Ubiquiti Rocket M (PtP backhaul) 4: Ubiquiti RocketDish with Ubiquiti Rocket M (PtP backhaul) 5: Ubiquiti AirMax Omni with Ubiquiti Rocket M (PtMP) 6: Corporate campus with Ubiquiti NanoBridge M clients 7: Mobile computer with Ubiquiti AirGrid M client Ubiquiti AirMax Omni Illustration Ubiquiti Omni AirMax MiMo Antenna 2.4GHz 13dBi – Technical Specifications Utilize Ubiquiti AirMax Technology* Unlike standard WiFi protocol, Ubiquiti’s Time Division Multiple Access (TDMA) AirMax protocol allows each client to send & receive data using pre-designated time slots scheduled by an intelligent AP controller. Intelligent QoS – Priority is given to voice/video for seamless access. Scalability – High capacity and scalability. Long Distance – Capable of high speed Carrier Class links Latency – Multiple features dramatically reduce noise. Ubiquiti AirMax Omni Antenna Technical Specifications (AMO-2G13) Frequency Range: 2.35 – 2.55 GHz Gain: 13 dBi Elevation Beamwidth: 12 deg / 7 deg Max VSWR: 1.7:1 Downtilt: 4 deg / 2 deg Dimensions: (l x w x h) 217 x 123 x 1011 mm / 217 x 123 x 1386 mm Weight: 2.1 kg / 2.4 kg Wind Loading: 28 lb @ 100 mph / 38 lb @ 100 mph Wind Survivability: 125 mph / 100 mph Polarization: Dual Linear Cross-pol Isolation: 25 dB min ETSI Specification: EN 302 326 DN2 Mounting: Universal pole mount, Rocket M bracket and weatherproof RF jumpers included Downloads Product Datasheet Please visit the Ubiquiti Firmware page for the latest Firmware upgrades
