Ubiquiti AP-5AC-90-HD airPRISM 5 GHz, 3×30° HD Sector Antenna
$65.52
$107.45
The innovative AP-5AC-90-HD airPrism® Antenna features significant advances in noise isolation and beam performance for co‑location deployments in a multi-point network. 3 x 30° Beamwidth Coverage The three Rocket5ac Prism™ radios are installed at the top, middle, and bottom of the airPrism antenna. Each radio independently transmits and receives within its corresponding 30° beamwidth. Powerful Performance Highly resistant to noise interference, the airPrism antenna provides superior beam performance in high-density areas for high-capacity, multipoint networks. Breakthrough Design Mounted on a single airPrism antenna, three Rocket5ac Prism radios maximize throughput in an efficient tower footprint, minimizing installation and tower costs. Antenna Characteristics Dimensions* 322.6 x 201.5 x 1300 mm Weight 13.1 kg (28.9 lb) Frequency Range 5.15 – 5.85 GHz Gain 22 dBi Polarization Dual-Linear Cross-Polarization Isolation 30 dB Min Interfaces (6) RP-SMA Connectors (Weatherproof) Compatible Radio Rocket5ac Prism, model Wind Survivability 200 km/h (125 mph) Mounting Universal Pole Mount, Rocket Bracket, and Weatherproof RF Connectors Included ETSI Specification EN 302 326 DN2
