The Ubiquiti PowerBeam AC 620 has excellent features such as improved noise immunity, innovative mechanical design as well as 5 GHz frequency and throughput. The ability to block and filter out noise is perfect for crowded areas with other RF signals of the same or similar frequency. PowerBeam AC PBE-5AC-620 Key Features Frequency: 5 GHz Throughput: 450 Mbps Range: 30 km Uniform Beamwidth Maximizes Noise Immunity Innovative Mechanical Design High-Speed Processor for Superior Performance Incorporating a dish reflector design with proprietary airMAX ac technology, the PowerBeam AC 620 is ideal for CPE deployments requiring maximum performance as it directs RF energy through a tighter beamwidth. InnerFeed Technology Ubiquiti’s InnerFeed technology integrates the radio into the feedhorn of an antenna, so there is no need for a cable. This improves performance because it eliminates cable losses. This feature, coupled with its high-performance and innovative mechanical design, makes the PowerBeam AC PBE-5AC-620 versatile and cost-effective to deploy. Ubiquiti PowerBeam AC PBE-5AC-620 – Technical Specifications System and Regulatory/Compliance Processor Specs Atheros MIPS 74Kc, 720 MHz Memory 128 MB DDR2, 8 MB Flash Networking Interface (1) 10/100/1000 Ethernet Port Wireless Approvals FCC, IC, CE RoHS Compliance Yes Physical/Electrical/Environmental Dimensions: 620 x 620 x 386 mm (24.41 x 24.41 x 15.2″) Weight: 6.4 kg (14.11 lb) Power Supply: 24V, 0.5A Gigabit PoE Power Method: Passive PoE (Pairs 4, 5 ; 7, 8 Return) Max. Power Consumption: 8.5W Gain: 29 dBi Operating Frequency: Worldwide (5150 – 5875 MHz), USA (5725 – 5850 MHz) Wind Loading: 872 N @200 km/h (196 lbf @125 mph) Wind Survivability: 200 km/h (125 mph) LEDs: (1) Power, (1) LAN, (4) WLAN Signal Strength: LEDs Software-Adjustable to Correspond to Custom RSSI Levels Channel sizes: PtP Mode (10/20/30/40/50/60/80 MHz, PtMP Mode (10/20/30/40 MHz) Polarisation: Dual Linear Enclosure: Outdoor UV Stabilised Plastic Mounting: Pole-Mount Kit Included ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV Operating Temperature: -40 to 70° C (-40 to 158° F) Operating Humidity: 5 to 95% Non-Condensing Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5 Vibration Test: IEC 68-2-6 Temperature Shock Test: IEC 68-2-14 UV Test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4 Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
