Description Camera Specifications Image Sensor Bullet channel: 1/2.5″ Progressive Scan CMOS PTZ channel: 1/2.8″ progressive scan CMOS Max. Resolution Bullet channel: 3632 × 1632 PTZ channel: 1920 × 1080 Low Light Performance Bullet channel: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light PTZ channel: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR Shutter Speed Range: 1 s to 1/30,000 s Day & Night Mode ICR Technology Facilitates seamless transition between day and night vision. Zoom PTZ channel: 25 × optical, 16 × digital Slow Shutter Supported Lens Details Focal Length Bullet channel: 2.8 mm PTZ channel: 4.8 to 120 mm, 25 × optical Field of View (FOV) Bullet channel: Horizontal: 180±10° Vertical: 80±5° PTZ channel: Horizontal: 54.8° to 2.8° (wide-tele) Vertical: 31.4° to 1.5° (wide-tele) Diagonal: 62.2° to 3.2° (wide-tele) Focus Options: Semi-auto, manual, auto Aperture Bullet channel: F1.0 PTZ channel: F1.6 Zoom Speed PTZ channel: approx. 3.6 s Illuminator Supplement Light Type PTZ channel: IR Bullet channel: White Light Supplement Light Range PTZ channel: up to 100 m Bullet channel: up to 30 m Smart Supplement Light Yes PTZ Features Movement Range (Pan/Tilt) Pan: 360° Tilt: -15° to 90° (auto flip) Speed Control Pan speed: configurable from 0.1° to 80°/s Tilt speed: configurable from 0.1° to 80°/s Presets Supports 300 presets Video Main Stream Bullet channel: 50 Hz: 25 fps 60 Hz: 30 fps PTZ channel: 50 Hz: 25 fps 60 Hz: 30 fps Video Compression Supports H.265, H.264, MJPEG Video Bit Rate Range: 32 kbps to 16384 kbps Network Protocols IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, SNMP, DNS, RTSP, TCP/IP, UDP, IGMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets, etc. Simultaneous Live View Up to 20 streams Security Supports authenticated access, MAC address binding, HTTPS encryption, IP address filter, etc. Audio Audio Compression G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC, MP3 Audio Bit Rate Varies based on compression type Audio Sampling Rate Varies based on compression type Image Features Image Parameters Allows adjustment of sharpness, saturation, brightness, and contrast. Day/Night Switch Supports day, night, auto, and scheduled-switch modes. Wide Dynamic Range (WDR) Provides 120 dB WDR for improved image clarity. Interface Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port On-Board Storage Built-in memory card slot supports up to 256 GB Micro SDXC cards Alarm 1 input, 1 output General Power 12VDC, PoE Dimension and Weight Dimensions: Ø 166 mm × 375 mm (Ø 6.5″ × 14.7″) Weight: Approx. 2.4 kg (13.2 lb.) Operating Condition Temperature: -30°C to 65°C (-22°F to 149°F), Humidity: <90%RH Material ADC12 Approval IP66 Standard, 6000 V Lightning Protection, Surge Protection, and Voltage Transient Protection
