Description Camera Specifications: Image Sensor: 2 MP CMOS Max. Resolution: 1920 (H) × 1080 (V) Min. Illumination: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR Shutter Time: PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s Day & Night: ICR Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360° Signal System: PAL/NTSC Lens: Lens Type: 2.8 mm, 3.6 mm fixed focal lens Focal Length & FOV:2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118 | 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92° Lens Mount: M12 Illuminator: Supplement Light Type: White Light; IR Supplement Light Range: IR: Up to 30 m | White Light: Up to 20 m Image: Image Settings: Brightness, Sharpness, Smart IR Frame Rate: TVI: 1080P @ 30 fps, 1080P @ 25 fps AHD: 1080P @ 30 fps, 1080P @ 25 fps CVI: 1080P @ 30 fps, 1080P @ 25 fps CVBS: PAL/NTSC Day/Night Mode: Auto/Color/BW (Black and White) Wide Dynamic Range (WDR): Digital WDR Image Enhancement: DWDR/BLC/HLC/Global White Balance: Auto/Manual AGC: Yes Interface: Video Output: Switchable TVI/AHD/CVI/CVBS Built-In Microphone: Yes General: Material: Metal Dimension: 80 mm × Ø85.1 mm (3.1″ × Ø3.4″) Weight: Approx. 296 g (0.65 lb.) Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) Communication: HIKVISION-C Language: English Power Supply: 12 VDC ± 25% You are recommended to use one power adapter to supply power for one camera. Consumption: Max. 3.3 W Approval: Protection: IP67
