Description Dimension Parameters: Tunnel Size: 500mm (W) × 300mm (H) Specification Parameters: Max. Load: 100 kg (220.46 lb) Conveyor Speed: 0.22 m/s Performance Parameters: Penetration: Standard 8mm, customizable up to 10 mm Wire Resolution: 40AWG Spatial Resolution: Vertical: 1.0 mm (0.04″) Horizontal: 1.0 mm (0.04″) General Standard: Power Consumption: 0.5 kW Weight: 290 kg (639.34 lb) Radiation Dose: X-Ray Dose Per Inspection: < 5 μGy X-Ray Leakage: < 1 μGy/h Other Parameters: X-Ray Generator: Anode Voltage: Standard 80 kV, 100% Oil Cooling General: Power Supply: 220 VAC/110 VAC (-10% to 15%), 50 Hz /60 Hz (±3 Hz) Working Temperature: 0 °C to 40 °C (41 °F to 104 °F) Working Humidity: 0% to 90% Dimension: 1586mm × 1160mm × 760mm (L x H x W) Other Details AI-XSP HD Image Algorithm: Utilizes advanced image processing technology to enhance image resolution, capable of detecting copper wire as fine as AWG40 (φ0.0787mm). Radiation Leakage: Meets environmental safety standards for radiation leakage. Integration with Hik-central: Supports connectivity to Hik-central for data upload. Data Storage: Allows for local storage of images and alarm information, enabling viewing and playback. Event Tracing: Enables correlation of X-ray images with passenger video data for comprehensive human package tracing. Quality and Reliability: Features a new design and precise manufacturing technology, ensuring high standards of quality control and product reliability.
