$14.04
$18.67
Camera Sensor 1/2.7″, 2.0 megapixel, progressive scan, CMOS Lens
[email protected] [email protected] DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m) 2.8 42 16.8 8.4 4.2 4.0 60 24 12 6 Angle of View (H) 112.7° 91.2° Angle of View (V) 60.1° 47.9° Angle of View (O) 121.2° 95.9° Adjustment Angle Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotate: 0° ~ 360° Shutter Auto/Manual, 1 ~ 1/100000s Minimum Illumination Colour: 0.02Lux ( F2.0, AGC ON) 0Lux with IR Day/Night IR-cut filter with auto switch (ICR) Digital noise reduction 2D/3D DNR S/N >52dB IR Range Up to 30m (98ft) IR range Wavelength 850nm IR On/Off Control Auto/Manual Defog Digital Defog WDR 120db Video Video Compression Ultra 265, H.265, H.264, MJPEG H.264 code profile Baseline profile, Main Profile, High Profile Frame Rate Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps Sub Stream: 720P (1280*720), Max 30fps; Video Bit Rate 128 Kbps~16 Mbps OSD Up to 4 OSDs Privacy Mask Up to 4 areas ROI Up to 8 areas Motion Detection Up to 4 areas Image White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 Digital noise reduction 2D/3D DNR Smart IR Support Flip Normal/Vertical/Horizontal/180° Dewarping Support HLC Supported BLC Supported Smart Behavior Detection Human Body Detection, Motion Detection, Tampering Alarm Network Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL Compatible Integration ONVIF (Profile S, Profile G, Profile T), API Client EZStation EZView EZLive Web Browser Plug-in required live view: IE9 , Chrome 41 and below, Firefox 52 and below Plug-in free live view: Chorme 57.0 , Firefox 58.0 , Edge 16 , Safari 11 Storage Edge Storage Micro SD, up to 128GB Network Storage ANR Interface Network 10/100M Base-TX Ethernet Certifications Certifications CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 General Power DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 4.5W Dimensions (L × W × H) 165 × 63.1 × 62.5mm (6.5” × 2.5” × 2.5”) Net Weight 0.45kg (0.99lb) Material Sun shield：plastic Front cover：metal Body：metal Bracket：metal Bottom plate：metal Working Environment -35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing) Storage Environment -35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing) Surge Protection 2KV Ingress Protection IP67
