Description Other Features: Set mode and initial set mode menu for easy operation Rapid scanning speed of 40 channels per second (during program scanning) Microphone with simple remote control using optional HM-75A LED backlighting for the LCD PC cloning capability Reverse shift function Auto squelch delay Specifications: General: Frequency Range: Tx: 144–148MHz Rx: 136–174MHz* (*Guaranteed range 144–148MHz) Mode: FM (F3E, F2D) Number of Memory Channels: 107 (including 6 scan edges and 1 call) Frequency Stability: ±10ppm (-10°C to 60°C) Operating Temperature Range: –10°C to 60°C; 14°F to 140°F Power Supply: 7.2 V DC (6.0–10.3 V DC acceptable with Icom’s battery pack only) Current Drain (at 7.2V DC): Tx: 5.5W: 2.0A 0.5W: 0.8A Rx: Max. Audio: 250mA Standby: 70mA Power Saved: 20mA Antenna Connector: BNC (50Ω) Dimensions (excluding projections): 54(W)×132(H)×35(D) mm / 2 1/8(W)×5 3/16(H)×1 3/8(D) in Weight (approx.): 350 g; 12.3 oz (with BP-222) Transmitter: Output Power (at 7.2 V DC): 5.5 W (High) 0.5 W (Low) Spurious Emissions: Less than –60 dB Max. Frequency Deviation: ±5.0 kHz External Microphone Connector: 3-conductor 2.5 (d) mm (1/10″) / 2.2 kΩ Receiver: Receiving System: Double conversion superheterodyne Intermediate Frequencies: 1st: 21.7 MHz 2nd: 450 kHz Sensitivity: 0.16 µV (typical; at 12dB SINAD) Squelch Sensitivity: 0.10 µV (typical; at threshold) Selectivity: 65dB (typical) Intermodulation: 75dB (typical) Spurious and Image Rejection: 75dB (typical) Audio Output Power (at 7.2 V DC): 300mW with an 8Ω load External Speaker Connector: 2-conductor 3.5 (d) mm (1/8″) / 8Ω
