Features: 1.7 GHz quad-core processor Dual WAN ports (10G SFP and 2.5GbE RJ45) (8) GbE RJ45 ports, including (6) PoE and (2) PoE LAN ports (1) 10G SFP LAN port (1) 1.3″ LCM color touchscreen for at-a-glance network monitoring Customizable internet threat filtration and traffic identification for enhanced network security Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app 1U-sized, rack-mountable device Connect a SmartPower Redundant Power System to create an uninterruptible network Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5″ HDDs 128 GB integrated storage for full UniFi OS Application experience Mechanical Dimensions 442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24″) Weight 4.95 kg (10.91 lb) Enclosure materials Aluminium CNC, SGCC steel Mount material SGCC steel rack mount Hardware Processor Quad-Core ARM® Cortex®-A57 at 1.7 GHz System memory 4 GB DDR4 On-board storage 16 GB eMMC Integrated 128 GB SSD IDS/IPS throughput 3.5 Gbps* *Measured with iPerf3 Max. power consumption (excluding PoE output) 50W Power method (1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz (1) USP-RPS DC input, 52VDC, 3.94A Power supply AC/DC, Internal, 240W Supported voltage range 100 to 240VAC Management interfaces Ethernet Bluetooth Networking interfaces (1) WAN: 2.5 GbE RJ45 port (8) LAN: 1 GbE RJ45 ports SFP interfaces (1) WAN: 10G SFP (1) LAN: 10G SFP PoE interfaces (2) PoE IEEE 802.3at (pair A 1, 2 ; 3, 6-) (6) PoE IEEE 802.3af (pair A 1, 2 ; 3, 6-) Max. PoE wattage per port by PSE 802.3af 15.4W Max. PoE wattage per port by PSE 802.3at 30W Voltage range 802.3af mode 44 to 57V Voltage range 802.3at mode 50 to 57V ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV LCM display (1) 1.3″ touchscreen Bootup animation: bootup in progress Firmware upgrade icon: firmware upgrading Button Factory reset Operating temperature -10 to 40° C (14 to 104° F) Operating humidity 5 – 95% noncondensing Certifications CE, FCC, IC LEDs Ethernet White: link/activity SFP White: link/activity HDD White: disk activity Amber: disk error RPS Blue: ready
