Signal Tracking : 440 GNSS channel | GPS L1C, L1C, L2C, L2E, L5 | LONASS L1C / A, L2C / A, L2P, L3 | BeiDou B1, B2, B3 | Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B | SBAS L1C / A, L5 GNSS features : Start-up time: <10s, Start-up reliability:> 99.99% Supported data formats : RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2 | Output data formats: NMEA 0183, PJK aircraft coordinates, Binari code, Trimble GSOF Code differential GNSS positioning : Horizontal: ± 0.25m 1ppm | Vertical: ± 0.50m 1ppm Static GNSS positioning : Horizontal: ± 2.5mm 0.5ppm | Vertical: ± 5mm 0.5ppm RTK : Horizontal: ± 8mm 1ppm | Vertical: ± 15mm 1ppm RTK - Network positioning : Horizontal: ± 8mm 0.5ppm | Vertical: ± 15mm 0.5ppm RTK Start Time : 2 ~ 8s Dimensions : 17.5 x 17.5 x 8.3 cm Weight : 1.33 kg (including 2 batteries) OS : Linux buttons : Double operation button Receiver indicator lights : 5 different indicator indicators Links : 5PIN LEMO external power port RS232 | 7PIN external USB (OTG) Ethernet | Bluetooth 2.1 EDR standard - Bluetooth 4.0 standard, Android support Memory : 8GB SSD internal storage | External storage support up to 32GB | Up to 50Hz of raw data collection Operating temperature : -45 ° C ~ 60 ° C Storage temperature : -55 ° C ~ 85 ° C Moisture : 100% condensing Water and Dust resistance : IP67 Drop resistance : Resistant to fall from 2 mt Electricity : 9-25V DC Battery : Rechargeable | 7.4V 3400 mAh dual or single battery Battery time : Static: 14 hours | RTK: 10 hours | Traveling: 12 hours Radio modem : Built-in radio modem, 1W / 2W / 3W selectable | 7-8 km working range Frequency range : 410-470 MHz Connection protocols : TrimTalk450s, TrimMark3, SOUTH GSM / GPRS Modem : WCDMA / CDMA2000 / TDD-LTE / FDD-LTE 4G network modem, backward compatible 3G GPRS / EDGE NFC connection : Close distance connection between receiver and controller (10 cm) Wi-Fi standard : 802.11 b / g standard Wi-Fi Hotspot : Wi-Fi hotspot allows mobile devices to be connected and controlled externally by web servers Wi-Fi data link : The receiver's data link feature allows it to distribute and collect differential data over Wi-Fi Audible warning : Intelligent audio technology provides status indicator and usage guidance Audible warning languages : Turkish, Chinese, English, Korean, Russian, Portuguese and Spanish
